Model No：WG-80

Patent No：201530567966.9

Digital Night Vision Binocular Uses:

Hunting，Scouting game

Security and surveillance

Camping fun/exploring caves

Nighttime navigation

Night fishing and boating

Wildlife observation

Search and rescue

Specification

Outstanding optical clarity, high performance night vision

Wide field of view

Video out capable

Time lapse Function:YES

★5Mega Pixels CMOS vs image-intensifier tube

★In-view 1.5” TFT display

★TF card: up to 32G(no included)

Adjustable eyepiece

Powerful infrared spotlight

★980ft /300M viewing range

★Magnification(optical): 4

★Objective Size:φ50mm

★Digital Zoom： 5

Field of View: 7°

The Range of Ocular Adjustment:  ±1.8mm

Aperture：F=1.3

Eyepiece exit pupil Distance: 8mm

Eyepiece exit pupil Diameter: 12mm

Objective focal Distance:37.5mm

Infrared Illuminator: Yes ,850NM

★JPEG: 2592*1944,1600*1200,640*480

★Video:1280*720，640*480@30FPS with sound

Observing Distance(Low Light Environment):2m～∞

★Observing Distance(Full Dark Environment): 980ft /300M

TV Out:PAL or NTSC

★Language:English, French,German,Swedish,Japanese & Russian,Spanish

Power Voltage:6V or 6V Power bank

Rechargeable Battery: 4*AA,lithium,alkaline or NI-MH Battery

Up to 9 hours runtime without the use of infrared illuminator.

Up to 3-5 hour with IR illuminator on.

★Built-in 1 tripod mountable:YES

★TV Out :Device be a live Infrared surveillance camera connecting TV with TV cable

USB:1.1

★PC camera function:YES,Device be a live Infrared surveillance camera connecting Computer with USB cable

Water Resistance Standard：IPX4

Operating Temperature Range:-30-55°(Storage temperature: -40°C - 70°C)

CE,FCC.RoHs

L / W / H: 205ⅹ169ⅹ88 mm

Weight:    780g

Accessories:

User's Manual  *1

Cleaning Cloth  *1

Pouch  *1

USB Cable *1

TV Cable *1

Neck Strap *1
