SG-999V( new product)
IP68 Wide angle 140 degree 30MP HD 1080P Black IR game camera






FEATURES


Model No:SG-999V

                  Main features:

1: Wide angle 140 degree ,built in 2.0”TFT LCD Display

2: 0.2-0.4s trigger time,Fast Fire Continuous Shooting (1-9pics), never miss any important picture

3: Time Lapse Camera,Timer Switch(On/Off )Time Lapse programmable,Time Interval settings:  1s-24hours

4: 5/8/12/20/30MP ultra compact digital scouting camera

5: 2 /3/ 4X Digital Zoom

8: Motorized ICR (IR-Cut-Remove) for color or Black photos/ videos day and night. HD video (1280p) with soundIllumi-Night sensor provides bright, clear nighttime images

6:48pcs Black IR LED,super long detection range up to 23meters/75 Feet , takes clear pictures or videos (in black&white) even in the dark night, takes color pictures or videos under sufficient day

7: Capture mode: PIR camera or video, camera+video, time lapse, motion detection

8: Patented motion freeze function

9: Camera rename functionas: abc2 & or your company brand name.

10: Password protected,Camera is unable to use and review picture/video when it was stole.

11: Battery/SD card cover can be locked for security

12: Weather-proof for outdoor IP68, 3M cable to connect storage battery  (Available)or solar panel, can use for all the world ,and never afraid of power exhausted

13: Enhanced night IR 140degrees of light front Open for easy access

14: Barometric pressure, moon phase, temperature, time, date and camera ID stamp,GPS ID stamp on the picture or video

15:1–60 minute picture delay ,User-friendly interface,40000 images on 8 AA batteries

16: 16 AA batteries(6V),12V DC,Unbeatable compact size: 132X 90 x60mm

                      Technical Specifications

Capture mode

 Photo,Video, Camera+Video,Time lapse

Display Screen

2.0" Color viewer TFT LCD

Image Sensor

30Mega Pixels Resolution,5 / 8 / 12 /20/30

Angle

PIR:140°

Lens

F=1.3; FOV=140° ;Max View 145°; Auto IR-Cut-Remove (at night)

Infrared Cut Filter

YES

IR-LED

48PCS 940nm black IR LED,0-23m/75ft

Memory

SD-card (not included)up to 64GB

Language

English,French,German,Swedish,Japanese

& Czech,Russian

Picture Size

12MP=4000x3000 / 8MP=3840x2160 / 5MP = 2944x1656

30MP=6400x4800 (JPEG)

Video Size

HD:1920x1080,1080x720 ,30fps (AVI)

Audio Recording

Available

Digital Zoom

2x, 3x, 4x

Camera+video

Yes

Password

Yes

Device serial no

Yes

Web camera function

Yes

Time lapse

On/Off

PIR detection

On/Off

Motion detection

On/Off

Trigger Time

0.2-0.4 s

Triggering Interval

1sec. - 60min. programmable (Available)

Shooting Numbers

1~9  programmable (Available)

Video Length

5-90sec. programmable(Available)

Image or video Overlays

Date,time,Moon Phase, temperature, barometric pressure, GPS  longitude &latitude,Camera ID

Power Supply

16 x AA Batteries or 12V DC (not included) or solar panel or 12V power bank or storage battery

Stand-by Current

< 0.2mA

Stand-by Time

Up to 12 Months(16*AA)

Power Consumption

170mA (±30mA when 48-IR-LED lighted total:<200mA)

Takes up to 40,000 pictures on 8*AA Alkaline batteries

Interface

TV out (NTSC,PAL); USB; SD card holder;TF card holder
12V DC external

Operation Temperature

-30°C - 60°C (Storage temperature: -40°C - 70°C)

Operation Humidity

5% - 90%

Waterproof spec

IP68

Size

132X 90 x60mm (Weight:400g)

Security authentication

CE FCC RoHS

Parts list

USB cable, TV out cable, belt, User manual, Warranty card







Packing:

Dimensions: mm x mm x mm [L/ W / H]

One gift box:* *mm, KG

20pcs/ctn

Gross weight:kg

Net wight:kg





Apply and purpose



1: Scouting game,Hunting/game camera for hunter or hobby, trail animals trace or habit

2: Wildlife observation,Monitor plant,animals growing up, ecological monitoring and researching

3Traffic/surrounding surveillanceCamping fun/exploring caves

4Security and surveillanceIndoor & outdoor security( Supermarket, warehouse, school, office, garden, mine filed, building site)
